ST1100 WASH GUN

ST1100 WASH GUN

SKU

Description

The Suttner ST1100 Wash Gun is a professional-grade, cost-effective solution for high-pressure cleaning tasks. Designed for versatility and durability, this entry-level wash gun is suitable for various applications, from industrial cleaning to automotive detailing.

Technical Spec

Inlet 3/8" Female
Outlet 1/4" Female
Max LPM 25 LPM
Bar 210
Colour Black
Max Temp °C 150
Commodity Code 8424200000
Weight 0.42
Country of Origin Germany

Datasheets

Need help?

Contact G&S 01768 865985

Overview

The Suttner ST1100 Wash Gun is a professional-grade, cost-effective solution for high-pressure cleaning tasks. Designed for versatility and durability, this entry-level wash gun is suitable for various applications, from industrial cleaning to automotive detailing.

Key Features:

  • Robust Construction: The gun features an impact-resistant casing and is built with corrosion-resistant materials, ensuring longevity and reliable performance in demanding environments.
  • High-Pressure Capability: With a maximum pressure rating of 210 bar (3,045 psi) and a flow rate of up to 25 liters per minute, the ST1100S efficiently handles tough cleaning tasks.
  • Temperature Resilience: Capable of withstanding temperatures up to 150°C, this wash gun is ideal for hot water cleaning applications.
  • Safety Lock: The integrated safety lock on the trigger prevents accidental activation, providing an added layer of security during operation.
Measurements

Wash Gun Opening/Holding forces

  • Opening Force: 35N @ 100 bar
  • Holding Force: 20N @ 100 bar
Measurements

Spare Parts

  • 1. Plastic housing with handle SKU: 020008510
  • 2. Plastic housing SKU: 020008520
  • 3. Trigger complete SKU: 201100505
  • 4. Valve housing SKU: 010006100
  • 5. Pipe inlet SKU: 070001397
  • 6. Inlet nut 3/8" female SKU: 010002600
  • 7. Piston rod SKU: 040005600
  • 8. Back ring SKU: 050000640
  • 9. O-Ring SKU: 050000260
  • 10. Seal support SKU: 010006120
  • 11. Spring SKU: 060000930
  • 12. O-ring SKU: 050000465
  • 13. Seal SKU: 040005610
  • 14. Stainless Steel ball SKU: 040000330
  • 15. Spring SKU: 060000940
  • 16. O-ring SKU: 050000210
  • 17. Screw plug SKU: 010006110
  • 18. Pin 4 x 25 SKU: 010001245
  • 19. Screw 3,5 x 16 SKU: 040000050
  • 20. Position is drop
